UniFi Network Video Recorder Professional | UNVR Pro

Liên hệ

  • 7 Khe gắn ổ cứng HDD / SSD 3,5″
  • 1 Cổng 10G SFP+ và 1 Cổng GbE RJ45
  • Bảo vệ dữ liệu với công nghệ lưu trữ RAID
  • Nguồn dự phòng với USP RPS
  • Màn hình cảm ứng 1.3″ để quản lý
UNVR-Pro
Dimensions 442 x 325 x 87 mm
Weight Without mounting brackets: 9.2 kg
With mounting brackets: 9.5 kg
Enclosure Material SGCC Steel
Mount material SGCC Steel
Management Interface Ethernet In-Band Management
Networking Interfaces (1) GbE RJ45 port
(1) 1/10 GbE SFP+ port
RF interface Bluetooth 4.1
Power Method (1) Universal AC input, 100—240V AC, 3A Max, 50/60 Hz
(1) USP-RPS DC input, 11.5V DC, 13.91A
Power Supply AC/DC, Internal, 200W
Supported voltage range 100—240V AC
Max. power consumption 160W
Max. power budget for Drives 135W
ESD/EMP Protection Air: ± 12kV, Contact: ± 8kV
LCM Display (1) 1.3″ touchscreen
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 5 – 95% Noncondensing
Certifications FCC, CE, IC
LEDs
System (1) Power: blue/white
Flashing white: bootup in progress
Flashing blue: firmware upgrading
Steady white: factory defaults, awaiting adoption
Steady blue: device is adopted
Ethernet Green: 1000 Mbps
Amber: 10/100 Mbps
SFP+ White: 10 Gbps
Green: 1 Gbps
HDD White: disk detected
Amber: disk error
RPS Blue: Ready
