Maipu PU2300-1G GPON SFU
Part Number |
: PU2300-1G
|
List Price |
: $Liên hệ ngay nhận giá tốt
|
Giá bán |
: Giá rẻ nhất thị trường
|
Bảo hành |
: 12 tháng
|
Made In |
: Liên hệ
|
Stock |
: Sẵn hàng
|
PU2300-1G cung cấp 1*GPON,1*GE
Thông số kỹ thuật
LED | Mark |
Color |
Status | Description |
system | SYS | Green | On | Device is powered on and starting. |
Blink | Device is running normally. | |||
Off | Device is powered off. | |||
Optical signal state | REG | Yellow | Blink | Device is not registered to the PON system. |
Green | Blink | Device is being registered. | ||
Green | On | Device is registered to the PON system. | ||
Interface | LINK/ACT | Green | On | Port is connected properly . |
Off | Port connection exception or not connected. | |||
Blink | Port is sending or/and receiving data |
Port Type | Function |
PON | Connect PON port with internet by SC/UPC type, single mode optical fiber cable. |
LAN | Connect device with ethernet port by RJ-45 cat5 cable. |
RST | Press down reset button and keep1-5seconds to make the device restart and recover from the factory default settings. |
DC12V | Connect with power adapter. |
|
Software Key Feature | |
Basic | Support MPCP discover & register |
Support authentication Mac/Loid/Mac + Loid | |
Support Triple Churning | |
Support DBA bandwidth | |
Support auto-detecting, auto-configuration, and auto firmware upgrade | |
Support authentication SN/Psw/Loid/Loid+Psw | |
Software mode | Bridging mode and Routing mode. |
Abnormal protection | Detecting Rogue ONU |
Security | DDOS, Filtering Based on ACL/MAC/URL. |
Alarm | Support Port Loop Detect |
Support Eth Port Los | |
LAN | Support Port rate limiting |
Support Loop detection | |
Support Flow control | |
Support Storm control | |
VLAN | Support VLAN tag mode |
Support VLAN transparent mode | |
Support VLAN trunk mode (max 8 vlan) | |
Support VLAN 1:1 translation mode (max 8 vlan) | |
Auto VLAN detection | |
Multicast | Support IGMPv1/v2 |
Support IGMP Snooping | |
Max Multicast vlan 8 | |
Max Multicast Group 64 | |
QoS | Support 4 queues |
Support SP and WRR | |
Support 802.1P | |
Management | Support CTC OAM 2.0 and 2.1 |
Support ITUT984.x OMCI | |
Support WEB/TELNET/CLI | |
Support TR069 |
