Ports |
|
2.5 GbE | 1 |
LAN |
|
DHCP |
DHCP Client
DHCP Server
DHCP Relay Agent
|
Static IP | ✓ |
Bind IP to MAC | ✓ |
802.1q tag-based VLAN | ✓ |
WLAN |
|
Band Type | Dual-Band |
WiFi 6 | ✓ |
OFDMA | ✓ |
Max. Clients | 256 |
2.4GHz WLAN | 802.11 b/g/n/ax |
5GHz WLAN | 802.11 a/n/ac Wave 2/ax |
Antennas | 5x Internal PIFA DB |
2.4GHz Antenna Gain (dBi) | 4.5 |
5GHz Antenna Gain (dBi) | 4.9 |
2.4GHz Max. Link Rate (Mbps) | 600 |
5GHz Max. Link Rate (Mbps) | 2400 |
Operating Mode |
AP
Mesh Root
Mesh Node
Range Extender
|
Max. Number of SSIDs (per band) | 16 (8) |
Security Mode |
OWE
WEP
WPA
WPA2/WPA
WPA2
WPA3/WPA2
WPA3
|
Authentication | Enterprise, Personal |
WMM | ✓ |
AirTime Fairness | ✓ |
Band Steering | ✓ |
Roaming |
AP-Assisted Roaming
Pre-Authentication
802.11r
802.11v
802.11k
|
WPS | PIN Code, WPS Button |
WDS | Repeater |
Objects |
|
Schedule | ✓ |
APP Notifications |
|
System |
WUI/SSH/Telnet Login
|
Wireless LAN |
Mesh Node online/offline
|
Authentication |
|
RADIUS Authentication | ✓ |
Certificates |
|
Local Certificates | ✓ |
Trusted CA | ✓ |
Local Services | ✓ |
Backup & Restore | ✓ |
Security |
|
MAC Address Filter (Max. entry number) | 128 |
Monitoring |
|
DHCP Table | ✓ |
ARP Table | * |
LLDP Neighbors information | ✓ |
Web Syslog | ✓ |
Internet Detection | ✓ |
Clients List | ✓ |
Utility |
|
Ping Tool | ✓ |
Trace Tool | ✓ |
Web CLI | ✓ |
System Maintenance |
|
Syslog | ✓ |
SNMP | v1, v2c, v3 |
Firmware Upgrade |
TFTP, TR-069, WUI
|
Backup/Restore | ✓ |
Role-based Privilege | ✓ |
System Reboot | ✓ |
Management |
|
Service Control |
HTTP
HTTPS
Telnet
|
TR-069 |
ACS and CPE Settings
|
Mesh | Node, Root |
Virtual AP Controller (Device up to) | 20 |
VigorConnect Management (Since f/w) | V1.5.4 |
VigorACS Management (Since f/w) | V1.5.4 |
PoE |
|
PoE Input Power Supply | 48V @ 0.32A |
PoE Input | PoE+ (802.3af/at) |
Physical |
|
Environment | Indoor |
Mounting | Ceiling / Wall |
Powered via | DC / PoE |
Power Input | 12V DC @ 1.5A |
Max. Power Consumption (watts) | 12 |
Dimension (mm) | 190 x 190 x 30 |
Weight (g) | 390 |
Operating Temperature | 0 to 40°C |
Storage Temperature | -20 to 60°C |
Operating Humidity (non-condensing) | 10 to 90% |
